Brushless Generators
Rugged, reliable, efficient, high quality, & All American
Our manufacture built alternators tailored, hi quality, and superior pricing
You need a price? You need a quote? Or you have a questions? Click Here
13.5 kW Generator Head 164B - Single Bearing
16.5 kW Generator Head 164D - Single Bearing
21 kW Generator Head 184E - Single Bearing
25 kW Generator Head 184F - Single Bearing
30 kW Generator Head 184G - Single Bearing
40 kW Generator Head 184J - Single Bearing
50 kW Generator Head 224D - Single Bearing
60 kW Generator Head 224E - Single Bearing
70 kW Single Bearing
80 kW Single Bearing
100 kW Single Bearing
150 kW Single Bearing
170 kW Single Bearing.
200 kW Single Bearing
225 kW Single Bearing
250 kW Single Bearing
250 kW Single Bearing
300 kW Single Bearing
400 kW Single Bearing
475 kW Single Bearing
500 kW Single Bearing
600 kW Single Bearing
650 kW Single Bearing
Custom Single Bearing Alternator
13.5 kW Generator Head 164B - Single Bearing
13.5 kW Generator Head 164B – Single Bearing
- PDG INDUSTRIAL 164 C 13.5KW
- Auxiliary Boost Winding (150% boost of rated power for 5 seconds)
- AVR AS440+
- Winding 06 – 4 Wire 1PH / Winding 311 – 12 Wire 3PH
- Class H Insulation
- 60 HZ
- 4 Pole 1800 RPM
- 1.0 Power Factor 1PH / .8 Power Factor 3PH
- Temp Rise/Ambient (125/40)
- Unit Weight: 260lbs.
- Single Bearing (direct connect through SAE bellhousing & flywheel)
- 19HP Diesel engine required for full output, may use engine with less HP but will not produce full output
- 27HP Gas engine required for full output, may use engine with less HP but will not produce full output
Click Here16.5 kW Generator Head 164D - Single Bearing
16.5 kW Generator Head 164D – Single Bearing
- PDG INDUSTRIAL 164 D 16KW
- Auxiliary Boost Winding (150% boost of rated power for 5 seconds)
- AVR AS440
- Winding 311 – 12 Wire
- Class H Insulation
- 60 HZ
- 4 Pole 1800 RPM
- .8 Power Factor
- Temp Rise/Ambient (125/40)
- Unit Weight: 275lbs.
- Single Bearing (direct connect through SAE bellhousing & flywheel)
- 23HP Diesel engine required for full output, may use engine with less HP but will not produce full output
- 32HP Gas engine required for full output, may use engine with less HP but will not produce full output
21 kW Generator Head 184E - Single Bearing
21 kW Generator Head 184E – Single Bearing
- PDG INDUSTRIAL 184 E 21KW
- Auxiliary Boost Winding (150% boost of rated power for 5 seconds)
- AVR AS440
- Winding 06 – 4 Wire
- Class H Insulation
- 60 HZ
- 4 Pole 1800 RPM
- 1.0 Power Factor
- Temp Rise/Ambient (125/40)
- Unit Weight: 355lbs.
- Single Bearing (direct connect through SAE bellhousing & flywheel)
- 30HP Diesel engine required for full output, may use engine with less HP but will not produce full output
- 42HP Gas engine required for full output, may use engine with less HP but will not produce full output
25 kW Generator Head 184F - Single Bearing
25 kW Generator Head 184F – Single Bearing
- PDG INDUSTRIAL 184 F 25KW
- Auxiliary Boost Winding (150% boost of rated power for 5 seconds)
- AVR AS440
- Winding 06 – 4 Wire
- Class H Insulation
- 60 HZ
- 4 Pole 1800 RPM
- 1.0 Power Factor
- Temp Rise/Ambient (125/40)
- Unit Weight: 405lbs.
- Single Bearing (direct connect through SAE bellhousing & flywheel)
- 36HP Diesel engine required for full output, may use engine with less HP but will not produce full output
- 50HP Gas engine required for full output, may use engine with less HP but will not produce full output
30 kW Generator Head 184G - Single Bearing
30 kW Generator Head 184G – Single Bearing
- PDG INDUSTRIAL 184 G 30KW
- Auxiliary Boost Winding (150% boost of rated power for 5 seconds)
- AVR AS440
- Winding 06 – 4 Wire 1PH / Winding 311 – 12 Wire 3PH
- Class H Insulation
- 60 HZ
- 4 Pole 1800 RPM
- 1.0 Power Factor 1PH / .8 Power Factor 3PH
- Temp Rise/Ambient (125/40)
- Unit Weight: 425lbs.
- Single Bearing (direct connect through SAE bellhousing & flywheel)
- 43HP Diesel engine required for full output, may use engine with less HP but will not produce full output
- 60HP Gas engine required for full output, may use engine with less HP but will not produce full output
40 kW Generator Head 184J - Single Bearing
40 kW Generator Head 184J – Single Bearing
- PDG INDUSTRIAL 184 J 40KW
- Auxiliary Boost Winding (150% boost of rated power for 5 seconds)
- AVR AS440
- Winding 06 – 4 Wire 1PH / Winding 311 – 12 Wire 3PH
- Class H Insulation
- 60 HZ
- 4 Pole 1800 RPM
- 1.0 Power Factor 1PH / .8 Power Factor 3PH
- Temp Rise/Ambient (125/40)
- Unit Weight: 500lbs.
- Single Bearing (direct connect through SAE bellhousing & flywheel)
- 57HP Diesel engine required for full output, may use engine with less HP but will not produce full output
- 80HP Gas engine required for full output, may use engine with less HP but will not produce full output
50 kW Generator Head 224D - Single Bearing
50 kW Generator Head 224D – Single Bearing
- PDG INDUSTRIAL 224 D 52KW
- Auxiliary Boost Winding (150% boost of rated power for 5 seconds)
- AVR AS440
- Winding 311 – 12 Wire
- Class H Insulation
- 60 HZ
- 4 Pole 1800 RPM
- .8 Power Factor
- Temp Rise/Ambient (125/40)
- Unit Weight: 615lbs.
- Single Bearing (direct connect through SAE bellhousing & flywheel)
- 74HP Diesel engine required for full output, may use engine with less HP but will not produce full output
- 104HP Gas engine required for full output, may use engine with less HP but will not produce full output
60 kW Generator Head 224E - Single Bearing
60 kW Generator Head 224E – Single Bearing
- PDG INDUSTRIAL 224 E 60KW
- Auxiliary Boost Winding (150% boost of rated power for 5 seconds)
- AVR AS440
- Winding 311 – 12 Wire
- Class H Insulation
- 60 HZ
- 4 Pole 1800 RPM
- .8 Power Factor
- Temp Rise/Ambient (125/40)
- Unit Weight: 670lbs.
- Single Bearing (direct connect through SAE bellhousing & flywheel)
- 86HP Diesel engine required for full output, may use engine with less HP but will not produce full output
- 120HP Gas engine required for full output, may use engine with less HP but will not produce full output
70 kW Single Bearing
70 kW Single Bearing
-
- Model PDG Industrial 224F
- kW 70
- RPM 1800
- Hz 60
- Bearing Single
- AVR AS440
- Weight 772
- HP Requirement Diesel 108
- HP Requirement Gas 140
80 kW Single Bearing
80 kW Single Bearing
-
- Model PDG Industrial 224G
- kW 80
- RPM 1800
- Hz 60
- Bearing Single
- AVR AS440
- Weight 860
- HP Requirement Diesel 128
- HP Requirement Gas 166
100 kW Single Bearing
100 kW Single Bearing
-
- Model PDG Industrial 274C
- kW 100
- RPM 1800
- Hz 60
- Bearing Single
- AVR PMG
- Weight 860
- HP Requirement Diesel 154
- HP Requirement Gas 200
150 kW Single Bearing
150 kW Single Bearing
-
- Model PDG Industrial 274FS
- kW 150
- RPM 1800
- Hz 60
- Bearing Single
- AVR PMG
- Weight 1235
- HP Requirement Diesel 231
- HP Requirement Gas 300
170 kW Single Bearing.
170 kW Single Bearing
-
- Model PDG Industrial 274G
- kW 170
- RPM 1800
- Hz 60
- Bearing Single
- AVR PMG
- Weight 1345
- HP Requirement Diesel 262
- HP Requirement Gas 340
200 kW Single Bearing
200 kW Single Bearing
-
- Model PDG Industrial 274H
- kW 200
- RPM 1800
- Hz 60
- Bearing Single
- AVR PMG
- Weight 1435
- HP Requirement Diesel 308
- HP Requirement Gas 400
225 kW Single Bearing
225 kW Single Bearing
-
- Model PDG Industrial 274J
- kW 225
- RPM 1800
- Hz 60
- Bearing Single
- AVR PMG
- Weight 1755
- HP Requirement Diesel 346
- HP Requirement Gas 450
250 kW Single Bearing
250 kW Single Bearing
-
- Model PDG Industrial 274K
- kW 250
- RPM 1800
- Hz 60
- Bearing Single
- AVR PMG
- Weight 1755
- HP Requirement Diesel 385
- HP Requirement Gas 500
250 kW Single Bearing
250 kW Single Bearing
-
- Model PDG Industrial 444C
- kW 250
- RPM 1800
- Hz 60
- Bearing Single
- AVR PMG
- Weight 2075
- HP Requirement Diesel 385
- HP Requirement Gas 500
300 kW Single Bearing
300 kW Single Bearing
-
- Model PDG Industrial 444D
- kW 300
- RPM 1800
- Hz 60
- Bearing Single
- AVR PMG
- Weight 2215
- HP Requirement Diesel 462
- HP Requirement Gas 600
400 kW Single Bearing
400 kW Single Bearing
-
- Model PDG Industrial 444F
- kW 400
- RPM 1800
- Hz 60
- Bearing Single
- AVR PMG
- Weight 2700
- HP Requirement Diesel 615
- HP Requirement Gas 800
475 kW Single Bearing
475 kW Single Bearing
-
- Model PDG Industrial K444F
- kW 475
- RPM 1800
- Hz 60
- Bearing Single
- AVR PMG
- Weight 2700
- HP Requirement Diesel 731
- HP Requirement Gas 950
500 kW Single Bearing
500 kW Single Bearing
-
- Model PDG Industrial 544D
- kW 500
- RPM 1800
- Hz 60
- Bearing Single
- AVR PMG
- Weight 3285
- HP Requirement Diesel 769
- HP Requirement Gas 1000
600 kW Single Bearing
600 kW Single Bearing
-
- Model PDG544E
- kW 600
- RPM 1800
- Hz 60
- Bearing Single
- AVR PMG
- Weight 3615
- HP Requirement Diesel 923
- HP Requirement Gas 1200
650 kW Single Bearing
650 kW Single Bearing
-
- Model PDG544F
- kW 600
- RPM 1800
- Hz 60
- Bearing Single
- AVR PMG
- Weight 3975
- HP Requirement Diesel 1000
- HP Requirement Gas 1300
Custom Single Bearing Alternator
8.2 kW Double Bearing 1 & 3 Phase
11 kW Double Bearing
13.5 kW Double Bearing
16 kW Double Bearing
16.5 kW Double Bearing
21 kW Double Bearing
23 kW Double Bearing
25 kW Double Bearing
27.5 kW Double Bearing
30 kW Double Bearing
40 kW Double Bearing
50 kW Double Bearing
52 kW Double Bearing
83 kW Double Bearing
8.2 kW Double Bearing 1 & 3 Phase
8.2 kW Double Bearing 1 & 3 Phase
- Model PDG Industrial 164A2
- kW 8.2
- RPM 1800
- Hz 60
- Bearing Double
- AVR AS440
- Weight 229
- HP Requirement Diesel 12
- HP Requirement Gas 17
Need Technical Specifications, Pricing, and Shipping/Freight?
Click Here
Detail Specifications, Pricing, and Shipping/Feight quotes are available on Request.
11 kW Double Bearing
11 kW Double Bearing
- Model PDG Industrial 164B2
- kW 11
- RPM 1800
- Hz 60
- Bearing Double
- AVR AS440
- Weight 262
- HP Requirement Diesel 17
- HP Requirement Gas 22
Need Technical Specifications, Pricing, and Shipping/Freight?
Click Here
Detail Specifications, Pricing, and Shipping/Feight quotes are available on Request.
13.5 kW Double Bearing
13.5 kW Double Bearing
- Model PDG Industrial 164B2
- kW 13.5
- RPM 1800
- Hz 60
- Bearing Double
- AVR AS440
- Weight 222
- HP Requirement Diesel 21
- HP Requirement Gas 27
Need Technical Specifications, Pricing, and Shipping/Freight?
Click Here
Detail Specifications, Pricing, and Shipping/Feight quotes are available on Request.
16 kW Double Bearing
16 kW Double Bearing
- Model PDG Industrial 29
- kW 16.5
- RPM 1800
- Hz 60
- Bearing Double
- AVR AS440
- Weight 339
- HP Requirement Diesel 24
- HP Requirement Gas 32
Need Technical Specifications, Pricing, and Shipping/Freight?
Click Here
Detail Specifications, Pricing, and Shipping/Feight quotes are available on Request.
16.5 kW Double Bearing
16.5 kW Double Bearing
- Model PDG Industrial 164D2
- kW 16.5
- RPM 1800
- Hz 60
- Bearing Double
- AVR AS440
- Weight 339
- HP Requirement Diesel 24
- HP Requirement Gas 32
Need Technical Specifications, Pricing, and Shipping/Freight?
Click Here
Detail Specifications, Pricing, and Shipping/Feight quotes are available on Request.
21 kW Double Bearing
21 kW Double Bearing
- Model PDG Industrial 184E2
- kW 21
- RPM 1800
- Hz 60
- Bearing Double
- AVR AS440
- Weight 350
- HP Requirement Diesel 36
- HP Requirement Gas 48
Need Technical Specifications, Pricing, and Shipping/Freight?
Click Here
Detail Specifications, Pricing, and Shipping/Feight quotes are available on Request.
23 kW Double Bearing
23 kW Double Bearing
- Model PDG Industrial 184E2/3
- kW 21
- RPM 1800
- Hz 60
- Bearing Double
- AVR AS440
- Weight 350
- HP Requirement Diesel 36
- HP Requirement Gas 48
Need Technical Specifications, Pricing, and Shipping/Freight?
Click Here
Detail Specifications, Pricing, and Shipping/Feight quotes are available on Request.
25 kW Double Bearing
25 kW Double Bearing
- Model PDG Industrial 184F2
- kW 25
- RPM 1800
- Hz 60
- Bearing Double
- AVR AS440
- Weight 350
- HP Requirement Diesel 35
- HP Requirement Gas 46
Need Technical Specifications, Pricing, and Shipping/Freight?
Click Here
Detail Specifications, Pricing, and Shipping/Feight quotes are available on Request.
27.5 kW Double Bearing
27.5 kW Double Bearing
- Model PDG Industrial 184F2/3
- kW 27.5
- RPM 1800
- Hz 60
- Bearing Double
- AVR AS440
- Weight 350
- HP Requirement Diesel 35
- HP Requirement Gas 46
Need Technical Specifications, Pricing, and Shipping/Freight?
Click Here
Detail Specifications, Pricing, and Shipping/Feight quotes are available on Request.
30 kW Double Bearing
30 kW Double Bearing
- Model PDG Industrial 184G2
- kW 30
- RPM 1800
- Hz 60
- Bearing Double
- AVR AS440
- Weight 468
- HP Requirement Diesel 45
- HP Requirement Gas 60
Need Technical Specifications, Pricing, and Shipping/Freight?
Click Here
Detail Specifications, Pricing, and Shipping/Feight quotes are available on Request.
40 kW Double Bearing
40 kW Double Bearing
- Model PDG Industrial 184J2
- kW 40
- RPM 1800
- Hz 60
- Bearing Double
- AVR AS440
- Weight 474
- HP Requirement Diesel 60
- HP Requirement Gas 80
Need Technical Specifications, Pricing, and Shipping/Freight?
Click Here
Detail Specifications, Pricing, and Shipping/Feight quotes are available on Request.
50 kW Double Bearing
50 kW Double Bearing
- Model PDG Industrial 224E2
- kW 50
- RPM 1800
- Hz 60
- Bearing Double
- AVR AS440
- Weight 680
- HP Requirement Diesel 78
- HP Requirement Gas 104
Need Technical Specifications, Pricing, and Shipping/Freight?
Click Here
Detail Specifications, Pricing, and Shipping/Feight quotes are available on Request.
52 kW Double Bearing
52 kW Double Bearing
- Model PDG Industrial 224D2/3
- kW 50
- RPM 1800
- Hz 60
- Bearing Double
- AVR AS440
- Weight 680
- HP Requirement Diesel 78
- HP Requirement Gas 104
Need Technical Specifications, Pricing, and Shipping/Freight?
Click Here
Detail Specifications, Pricing, and Shipping/Feight quotes are available on Request.
83 kW Double Bearing
83 kW Double Bearing
- Model PDG Industrial 224G2/3
- kW 83
- RPM 1800
- Hz 60
- Bearing Double
- AVR AS440
- Weight 755
- HP Requirement Diesel 128
- HP Requirement Gas 166
Need Technical Specifications, Pricing, and Shipping/Freight?
Click Here
Detail Specifications, Pricing, and Shipping/Feight quotes are available on Request.
You need a price? You need a quote? Or you have a questions? Click Here
